性能特点 Performance Features
◆ 采用高强度机身构造，变形量小，精度高。
◆ 滑块采用四角六面导路，可承载较大的偏心负载，确保冲压精度的长期、稳定保持。
◆ 滑块导轨采用“高频淬火”+“导轨研磨工艺”，磨损小、精度高、精度保持时间长、提高模具使用寿命。
◆ 采用黄油润滑装置，设有自动报警功能。
◆ 曲轴采用高强度合金材质42CrMo，力学性能优于常用45钢材。
◆ 铜套采用锡磷青铜ZQSn10-1，综合强度优于常规BC6黄铜。
◆ 采用高灵敏液压过载保护装置，可有效保护冲床和模具使用寿命。
◆ 标配触摸屏。

◆ 可选配模垫（气垫）。

◆ Adopting high-strength body structure, with small deformation and high accuracy.
◆ The slider adopts four corners and six side guide, which can bear large eccentric load to ensure the long-term and stable maintenance of stamping accuracy.
◆ The slide rail adopts the "high-frequency quenching" and "rail grinding process", which has low wear, high accuracy, long accuracy retention time, and improves the service life of the mold.
◆ Butter lubrication device, with automatic alarm function.
◆ The crankshaft is made of high-strength alloy 42CrMo, which has superior mechanical properties compared to commonly used 45 steel.
◆ The copper sleeve is made of tin-phosphorus bronze ZQSn10-1, which has superior comprehensive strength compared to conventional BC6 brass.
◆ Adopting a highly sensitive hydraulic overload protection device can effectively protect the service life of the punching machine and mold.
◆ Standard touch screen.
◆ Optional mold pad (air cushion).
