性能特点  Performance Features

◆ 采用高强度机身构造，变形量小，精度高。
◆ 采用OMPI气动干式离合刹车器。
◆ 滑块采用两角六面导路，滑块导轨采用“高频淬火”+ “导轨研磨工艺”，磨损小，精度高，精度保持时间长，提高模具使用寿命。
◆ 曲轴采用高强度合金材质42CrMo，力学性能优于常用45钢材。
◆ 铜套采用锡磷青铜ZQSn10-1，综合强度优于常规BC6黄铜。
◆ 采用高灵敏液压过载保护装置，可有效保护冲床和模具使用寿命。
◆ 标配SMC调压阀、油雾器、空气过滤器。
◆ 可选配模垫（气垫）。

◆ Adopting high-strength body structure, with small deformation and high accuracy.
◆ Adopting OMPI pneumatic dry clutch brake.
◆ The slider adopts a hexagonal guide path with two corners, and the slider guide adopts a "high-frequency quenching" and "rail grinding process", which has low wear, high accuracy, long accuracy retention time, and improved mold service life.
◆ The crankshaft is made of high-strength alloy material 42CrMo, which has superior mechanical properties compared to commonly used 45 steel.
◆ The copper sleeve is made of tin-phosphorus bronze ZQSn10-1, which has superior comprehensive strength compared to conventional BC6 brass.
◆ Adopting a highly sensitive hydraulic overload protection device can effectively protect the service life of the punching machine and mold.
◆ Standard SMC pressure regulating valve, oil mist filter, and air filter.
◆ Optional mold pad (air cushion).
